The DDL-8000A Series maintains JUKI's established seam quality and is provided with narrowed-down essential and simplified functions. It helps improve the work efficiency through operator assistance with its audio guidance.
Voice guidance for assisting the operator
This sewing machine is provided as standard with the voice guidance with clock function
Production support function
The target number of products, work progress (current number of products produced, achievement rate) and the operating rate of the sewing machine are displayed on the control panel provided that the initial data have been properly set.
Since the USB port is provided as standard for the operation panel and control box, sewing data can be managed and the relevant software can be upgraded with ease.
DDL-8000A
Model name | DDL-8000AS-MS | DDL-8000AS-SH | DDL-8000AS-SJ | |
---|---|---|---|---|
Specification | Standard type | |||
Application | Medium-weight | Heavy-weight | Jeans・Heavy-weight | |
Lubrication | Semi-dry | Minute-quantity lubricationy | ||
Max. sewing speed | 5,000sti/min | 4,500sti/min | ||
Max. stitch length | 5mm | |||
Needle | DB×1 (#11) #9~#18 | DB×1 (#21) #20~#23 | DB×5 (#21) #20~#23 | |
Lift of the presser foot | By hand : 5.5mm, Auto : 1st stage 8.5mm, 2nd stage 13.0mm, By knee: 15mm |
Model name | DDL-8000AB-MS | DDL-8000AB-SH | DDL-8000AB-SJ |
---|---|---|---|
Specification | Shorter-thread remaining type | ||
Application | Medium-weight | Heavy-weight | Jeans・Heavy-weight |
Lubrication | Semi-dry | Minute-quantity lubricationy | |
Max. sewing speed | 5,000sti/min | 4,500sti/min | |
Max. stitch length | 5mm | ||
Needle | DB×1 (#11) #9~#18 | DB×1 (#21) #20~#23 | DB×5 (#21) #20~#23 |
Lift of the presser foot | By hand : 5.5mm, Auto : 1st stage 8.5mm, 2nd stage 13.0mm, By knee: 15mm |
